| Part Number | Maximum AllowableVoltageAC.rms(V) | Maximum AllowableVoltageDC(V) | VaristorVoltageV1mA(V)Min | VaristorVoltageV1mA(V)Ave | VaristorVoltageV1mA(V)Max | DC BreakdownVoltage(VBR) 100V/s (V) | CoordinatedCapacitance (V) | Up (kV) | Withstanding SurgeCurrentI n (kA) | Withstanding SurgeCurrentI max (kA) | IP code | Flame Rating | SizeLxWxH(mm) | 搜索 | |
| BSPDPV20K-670H1A | 510 | 670 | 612 | 680 | 748 | 1680V±20% | 0 | 1.5 | 10 | 20 | IP20 | UL94 V0 | 34.2x14.3x30.3 | ||
| BSPDPV20K-670H1 | 510 | 670 | 612 | 680 | 748 | 1680V±20% | 0 | 1.8 | 10 | 20 | IP20 | UL94 V0 | 34.2x14.3x30.3 | ||
| BSPDPV20K-670H2A | 510 | 670 | 612 | 680 | 748 | 1680V±20% | 47 | 1.5 | 10 | 20 | IP20 | UL94 V0 | 34.2x14.3x30.3 | ||
| BSPDPV20K-670H2 | 510 | 670 | 612 | 680 | 748 | 1680V±20% | 47 | 1.8 | 10 | 20 | IP20 | UL94 V0 | 34.2x14.3x30.3 | ||
| BSPDPV20K-900H1 | 900 | 900 | 612 | 680 | 748 | 1900V±20% | 0 | 2.6 | 10 | 20 | IP20 | UL94 V0 | 34.2x14.3x30.3 | ||
| BSPDPV20K-900H2 | 680 | 900 | 612 | 680 | 748 | 1900V±20% | 47 | 2.6 | 10 | 20 | IP20 | UL94 V0 | 34.2x14.3x30.3 | ||
| BSPDPV20K-560L | 420 | 560 | 612 | 680 | 748 | 680V±10% | 0 | 1.8 | 10 | 20 | IP20 | UL94 V0 | 33.5x12x30 | ||
| BSPDPV20K-825L | 625 | 825 | 612 | 680 | 748 | 1000V±10% | 0 | 2.6 | 10 | 20 | IP20 | IP20 | 33.5x12x30 |
